OUTLOOK














SPECIFICATION








Parameter/Par No

LY- ST31060XX

XX=PW/WW/NW



Battery

32700 LiFePO4 12.8V 36 Ah

Beam angle

150 X 60°

Pole diameter

60mm

Light output

max 60W

Luminous flux(lm)

10200

Color Temperature

Pure white:5000-6500K    Warm white:2700-3200K    Neutral white:4000-4500K

Solar panel

60W /18V  Monocrystalline silicon (Life span of 25 years, 80% efficiency)

CRI

>70

Chip Brand

LUXEON 5050

LED Quantity(PCS)

48

Operating time

Full power >12 hours ,Intelligent mode 3-4 days

(Affected by local use environment and sunlight)

Control Mode

Time control + Light sensor control + Motion sensor control

Material

Aluminum

Luminous efficiency(lm/w)

>170

Lifespan(h)

Three years

IP Rating

IP65

Installation height

6~7M

Size(mm)

hL1023*W373*H175mm   (L40.28*W14.69*H6.89 Inch)

Net Weigh(kg)

16

Package Size(mm)

L1077*W210*H430mm  (L42.40*W8.26*H16.93 Inch)

Package Quantity(Pcs) 1

Gross Weigh(kg)

18.0







APPLICATION






Suitable for the street lighting; sidewalk lighting;roadway lighting; fence lighting; pathway lighting; campus lighting; park lighting; garden lighting;ramp lighting;boat dock lighting; remote area lighting;farm & ranch lighting.







FEATURES






1>The intergration of design ,no cable,the installation is very convenient.

2>The Mono-crystalline solar panel,LED lights,lithium battery,intelligent controller integrated Aluminum  Alloy shell.

3>It used of lithium iron phosphate battery,fight the high temperature,keep long life.

4>When the products with optically controlled microwave induction infrared sensor, automatic adjustment of intelligent power on rainy days, extend rainy days.

5>It used of alloy material as the main structure,with good rust prevention,corrosion protection.

6>The wireless remote control setting device,adjustable lighting time ,lighting power ,automatic detection of battery voltage,read light power parameters,a human body induction function,as long as people go through when full power lighting,no automatic power down alf, restore energy saving mode.

7>time control + light sensor control+ motion sensor control

8>Motion and light sensor built in:solar street light goes on at dusk at 20% brightness(Brightness adjustable). Can go from 20% power to full brightness when motion is detected. Three Intelligent Modes: Bright / DIM / Recharge. 1、Bright: motion activates for lighting when motion is detected for security light and to save battery; 2、DIM: 20% lighting for saving power when no motion(Brightness adjustable); 3、Off/Recharge: automatically turns off in daylight and goes into recharge mode. (working mode can be adjusted according to client's demands).

60W SUNPLUS Solar LED Street Light
